Supply voltage
12-30 VDC
System solution
12-30 VDC
Via function modules in the switchboard:
For details, see basic units or electronic function modules of U-ONE Generation I (LWL).
approx. 2.5 kg (basic unit only) + weight of the individual modules
Details see electronic function modules of system solution U-ONE Generation I (LWL)
Details see basic units of system solution U-ONE Generation I (LWL)
Take a look at our animations for the steel, crane and port technology, and mining sectors! Click through our animations from a rough overview to the specific mounting location of an encoder and get direct suggestions for suitable encoder solutions.
U-ONE Generation I (LWL) is the first generation of the proven universal encoder system for speed and position monitoring. The encoder system consists of a basic unit on the application shaft and function modules in the switchboard.
The encoder signals are transmitted from the basic unit to the decoder module in the switchboard via two fiber optic cables – interference-free over distances of up to 1000 meters.
The universal encoder system U-ONE replaces mechanical overspeed switches and mechanical cam limit switches with more precise electronic speed switches and position switches. The encoder system does not require distribution gears, distribution couplings or speed increasing gears.
Optionally, the encoder system’s speed monitoring is certified for safety applications up to SIL 2 / PL d.
Components of the encoder system
The U-ONE encoder system comprises a basic unit and function modules in the switchboard – this is the ideal solution when there is sufficient space in the switchboard and FOC transmission is possible.
